2″ Stainless Steel Y Strainer
2″ stainless steel Y strainers are standard with drain connections and pipe plugs.
This 2″ stainless steel Y-strainer is made of high quality stainless steel (CF3/CF8/CF3M/CF8M) with 600# socket weld connections.
TOT 2″ stainless steel Y strainers are field installed with connections and drain valves, allowing for easy cleaning of the strainer screen while your piping system is still in operation.
If your piping system requires such a Y-Strainer, contact us today to get a very competitive ex-factory price.
Description
2″ Stainless steel Y strainers are an indispensable filtering device in your pipeline system for conveying media.
The TOT 2″ Stainless Steel Y-Strainer is designed for your industrial and commercial applications in harsh environments. You can protect your downstream pumps, meters, control valves, steam traps, regulators, and other process equipment with our Y-Strainer, which removes harmful solids from liquid, gas, or steam lines with its perforated or wire mesh screen.
This 2″ Stainless Steel Y-Strainer is made of high-quality stainless steel (CF3/CF8/CF3M/CF8M) and has 600# socket weld connections.
This Y-Strainer is cleaned manually by shutting off the line and removing the strainer, then clearing any debris from the strainer. This Y-Strainer can be mounted horizontally or vertically.
| Parts Name | Stainless Steel Y Strainer |
| Size | 2″ |
| Pressure | Class 150 / Class 300 |
| Standard Screen / Basket | Mesh 60 |
| Optional Mesh | 20/40/60/80/100 |
| Construction | Bolt Cover |
| Connection | FF |
| Body Material | CF3/CF8/CF3M/CF8M |
| Cover | F316/F304 |
| Design & Manufacture | ASME B16.34 |
| End to End | ASME B16.10 |
| End Connection | ASME B16.5 |
| Inspection | API 6D, API 598 |
| Temperature Range | -29℃~+538℃ |
| Medium | Oil, Water, Gas |
Main External and Connection Dimension
TOT Valve can provide you with Y strainers of various dimension and models.
We list 2″ stainless steel Y strainers dimensions, can be used for your reference. If you do not have the Y strainers size you need, you can contact us immediately. Our professional sales manager will contact you and can provide you with exclusive ODM and OEM services.
2″ Stainless Steel Y Strainers
| Pressure | L | D | D1 | D2 | b | f | z-Φd |
|---|---|---|---|---|---|---|---|
| Class 150 | 8.66 | 5.91 | 4.75 | 3.63 | 0.63 | 0.06 | 4-Φ0.75 |
| Class 300 | 8.66 | 6.5 | 5 | 3.63 | 0.91 | 0.06 | 8-Φ0.75 |
* We are not just providing simple quotes but experts in selection, calculation, and drawing.
